MUSEO FERROVIARIO MADRID-ANTIGUA ESTACION DELICIAS.- Vista panorámica de los andenes del Museo con diversas unidades.-
Photo: Gustavo Vieites
http://es.geocities.com/gustavovieites


MUSEO FERROVIARIO MADRID-ANTIGUA ESTACION DELICIAS.- Vista panorámica de uno de los andenes, en éste en concreto, se rodó parte del Film de David Lean de 1965 "Doctor Zhivago".-
Photo: Gustavo Vieites
http://es.geocities.com/gustavovieites


RENFE: Museo Delicias
Material pendiente de restauracion.
Locomotive dependent on restoration.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


RENFE: Museo Delicias
Material pendiente de restauracion.
Locomotive dependent on restoration.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


Hainaut #786 located at Madrid-Delicias railway museum. Detail shows replaceable friction bearings could be adjusted with a wedge as the wore down. El detalle muestra los cojinetes de fricción reemplazables y que podían ajustarse con una cuña según se iban desgastando.
Photo by Alfonso González 6 Jan 2007
(C) Alfonso González


Madrid - Delicias Railway Museum
RENFE class 1-4-0 2044 steam locomotive, formerly owned by Ferrocarriles Andaluces. It doesn't have any number plates, but it seems to have been lightly restored and painted.
31/12/2003 Delicias Railway Museum, Madrid.

Digital photo by Julio Castillo (jcastjr@telcom.es)


RENFE : 020
Locomotora vapor tipo 0-2-0, perteneciente al ferrocarril urbano de Jerez (1/3/1872), fue la locomotora mas pequeña en ancho español.
Steam locomotive type 0-2-0, belonging to the urban railroad of Jerez (1/3/1872), it was the locomotive but small in Spanish gauge.
Delicias (Madrid) - 8/1999

Photo: Carlos Pérez Arnau (carlosperez@studio3.es)


RENFE : 0-2-0
Antigua locomotora 020-0231, ex-MZA, construida en Belgica en 1885 por Usines Metalurgiques de Hainaut en Couillet (Belgica).
Old locomotive 020-0231, former-MZA, built in Belgium in 1885 for Usines Metalurgiques of Hainaut in Couillet (Belgium).
Museo del ferrocarril de Delicias (Madrid) 6/2001

Photo and scan: Carlos Perez Arnau / carlosperez@studio3.es


RENFE : 0-2-0
Antigua locomotora 020-0231, ex-MZA 601.
Old locomotive 020-0231, former-MZA 601.
Museo del ferrocarril de Delicias (Madrid) 6/2001

Photo and scan: Carlos Perez Arnau / carlosperez@studio3.es


RENFE : 0-2-0
Antigua locomotora 020-0231, ex-MZA, construida en Belgica en 1885 por Usines Metalurgiques de Hainaut en Couillet (Belgica).
Old locomotive 020-0231, former-MZA, built in Belgium in 1885 for Usines Metalurgiques of Hainaut in Couillet (Belgium).
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


Locomotora de Vapor 020-0231 de Renfe (Ex-MZA 601, Couillet, 1885), Museo de Madrid_Delicias, 25/05/2006.
Renfe 020-0231 (Ex-MZA 601, Couillet, 1885) steam locomotive, Madrid-Delicias Museum, 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)



RENFE: 1-2-0
Locomotora EL ALAGON Construida en 1861 por Parent Sahakem Oullins, para el fcc del Norte.
Locomotive THE ALAGON Constructed in 1861 by Parent Sahakem Oullins, for the fcc of the North.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


RENFE steam locomotive 0-3-0 2107 "El Alagón" with a kind of steam retrofitting from the cylinders, preserved at Madrid Delicias station (National Railways Museum).
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


RENFE steam locomotive 0-3-0 2107 "El Alagón". The metal stairs on the right helps visiting the cabin.
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


RENFE steam locomotive 0-3-0 2107 "El Alagón". Interior of the cabin seen from the bottom of the tender, luckily it wasn't full of coal.
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


RENFE steam locomotive 0-3-0 2107 "El Alagón". This is the driver's view from the interior of the cabin, usually he would see the track but here we see other locomotives of the museum.
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861, Ex-Norte 127, Ex Medina-Salamanca 9, Ex-Oeste 119) preservada en el Museo de Madrid-Delicias. 25/05/2006.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861, Ex-Norte 127, Ex Medina-Salamanca 9, Ex-Oeste 119) preserved at Madrid-Delicias Museum. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Detalle de la cabina. 25/05/2006.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Cab's detail. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)





Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Detalle de las bielas. 25/05/2006.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Rod's detail. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Detalle de la Carbonera del Tender. 25/05/2006.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Coal depot in Tender. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Detalle de la placa de la locomotora.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Plate's detail.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Detalle de la placa existente en los bajos del Tender, recordando una reforma del año 1901. La compañía de Medina del Campo a Salamanca decidió reformar esta locomotora en tres ocasiones: en 1877 (Realizada por Norte en Valladolid, en la que se transformó de 120 a 030); en 1901 (Gran reparación) y en 1918.
Renfe 030-2107, "El Alagón" (Parent & Schaken, 1861). Tender Plate's detail, that remember a transformation made by the Medina To Salamanca Rw. Co. (MS) in 1901. Another two transformations was made by MS over this locomotive: in 1877 (Ordered to its first Owner, the NORTE Co. , in which the axle system of the loco was changed from 120 to 030), and in 1918.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


Renfe 030-2107. Placa sobre el ténder. Museo de Madrid-Delicias, 25/05/2006.
Renfe 030-2107 steam locomotive. Tender's plate. Madrid-Delicias Museum, 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


RENFE: 0-4-0
Locomotora EL CINCA Construida en 1864 por Creusot, para el fcc del Norte.
Locomotive THE CINCA Constructed in 1864 by Creusot, for the fcc of the North.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


RENFE steam locomotive 0-4-0 2091, built in 1863 by Schneider for the Norte railway, preserved at Madrid Delicias station (National Railways Museum). Note the very large dome with the steam valves and the chimney with visor and cap.
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


Renfe 040-2091, "El Cinca" (Ex-Norte 501, -después 2501-, Schnneider, 1863). Museo de Madrid-Delicias, 25/05/2006.
Renfe 040-2091, "El Cinca" (Ex-Norte 501, -after 2501-, Schnneider, 1863). Madrid-Delicias Museum, 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


RENFE : 111
Locomotora vapor construida por "John Jones" para el ferrocarril de Tardienta-Huesca en 1864, posteriormente pertenecio a Norte. En 1910 fue vendida a la empresa privada Industrial Azucarera SA. En 1968 fue cedida a Renfe para el museo.
Locomotive vapor type 1-1-1 built by John Jones for the railroad of Tardienta-Huesca in 1864, later on it belonged to Norte. In 1910 it was sold to the Industrial Azucarera SA private company. In 1968 it was given Renfe for the museum.
Delicias (Madrid) - 8/1999

Photo: Carlos Pérez Arnau (carlosperez@studio3.es)


RENFE: 1-1-1
Construida en 1864 por John Jones, para el fcc de Tardienta a Huesca.
Constructed in 1864 by John Jones, for the fcc of Tardienta to Huesca.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es



RENFE steam locomotive 1-1-1 with two interior cylinders, built by John Jones in 1863 for the Tardienta-Huesca railway and preserved at Madrid Delicias station (National Railways Museum).
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


RENFE steam locomotive 1-1-1 built by John Jones in 1863 for the Tardienta-Huesca railway and preserved at Madrid Delicias station (National Railways Museum). Note the few and simple commands in the open cabin.
Photo by Julio Castillo Jr. (jcastjr@telcom.es)


Locomotora de Vapor de rodaje 111 número 2 del ferrocarril de Tardienta a Huesca (John Jones, 1864), preservada en el Museo de Madrid Delicias. 25/05/2006.
Nr. 2 Tardienta - Huesca Rw. Co. 111 Steam Locomotive (John Jones, 1864), preserved at Madrid-Delicias Museum. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


RENFE : 130
Locomotora vapor "Pucheta" tipo 1-3-0.
Steam locomotive "Pucheta" tipe 1-3-0.
Delicias (Madrid) - 8/1999

Photo: Carlos Pérez Arnau (carlosperez@studio3.es)


RENFE: 1-3-0
Locomotora PUCHETA Construida en 1884 por Sharp Stewart, para el fcc del Triano.
Locomotive PUCHETA Constructed in 1884 by Sharp Stewart, for the fcc of the Triano.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es



RENFE steam locomotive 1-3-0 0201 "Pucheta", built in 1887 by Sharp & Stewart for the Triano railway. This was the only 1-3-0 tender-locomotive in RENFE, and is now preserved at Madrid Delicias station (National Railways Museum).
Photo by Julio Castillo Jr. (jcastjr@telcom.es)






RENFE: 1-2-0
Construida en 1877 por Sharp Stewart, para el fcc TBF.
Constructed in 1877 by Sharp Stewart, for the fcc of TBF.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


Renfe 120-0211, Ex-MZA 176 (Sharp & Stewart, 1877). Madrid-Delicias. 25/05/2006.
Manuel Marcos (manueljosemarcosmontero@hotmail.com)


RENFE: 2-3-0
Locomotora Construida en 1907 por North British, para el fcc de Beira Alta.
Locomotive Constructed in 1907 by North British, for Beira Alta's fcc.
Station: Museo Delicias (Madrid) - 22/10/2005

Photo: Carlos Pérez Arnau carlosperez@studio3.es


RENFE steam locomotive 2-3-0 2059, built in 1907 by North British Locomotive for the Oeste railway company. Preserved at Madrid Delicias station (National Railways Museum).
Photo by Julio Castillo Jr. (jcastjr@telcom.es)
