The junction between the original (yellow hand rail) and extended (white hand rail) parts of the station footbridge at Filton Abbey Wood. When the third track and platform was added in 2004 for trains heading towards South Wales the original path was torn up and the footbridge extended over the new track and along the embankment.
Photo by Chris McKenna19/01/2006. |
|
When the third track and platform at Filton Abbey Wood station was added in 2004 for trains heading towards South Wales the original path from the car park was torn up and the footbridge extended over the new track and along the embankment. This photograph shows the route the old foot- and cyclepath is now blocked off and the new footpath is on the right.
Photo by Chris McKenna19/01/2006. |
|
The plaque at Filton Abbey Wood railway station commorating the opening of platform 3 on 2nd July 2004.
Photo by Chris McKenna19/01/2006. |
|
A closeup of the converging points immediately north of Filton Abbey Wood station. In this configuration the track is set for trains from Bristol Parkway.
Photo by Chris McKenna19/01/2006. |
|
A closeup of the converging points immediately north of Filton Abbey Wood station. In this configuration the track is set for trains from South Wales and Avonmouth via Brentry.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the top of the ramp to platform 1. Platform 1, nearest the camera, is for all southbound services. Platform 2, the next one over is served by trains heading northbound via Bristol Parkway; in the background the relatively new platform 3 takes trains heading for South Wales.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the approach footpath. The section of the bridge nearest the camera and those parts with white hand rails was added in 2004 when the third line (nearest the camera) was added to increase capacity by splitting northbound services heading via Bristol Parkway from those heading to South Wales. Before that the path from the car park ran at ground level from the back of platform 2.
Photo by Chris McKenna19/01/2006. |
|
A merged view of Filton Abbey Wood station viewed from the approach footpath. The section of the bridge nearest the camera and those parts with white hand rails was added in 2004 when the third line (nearest the camera) was added to increase capacity by splitting northbound services heading via Bristol Parkway from those heading to South Wales. Before that the path from the car park ran at ground level from the back of platform 2. The ramp with yellow handrails to platforms 2 and 3 (originally just platform 2) is original to the contstruction of the station, which is contemporary with the openeing of the large MOD complex in the background.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the approach footpath. The white line visible between the tracks dates from when this stretch of tarmac was a combined footpath and cycle track from the car park to the station, before the construction of the line in the foreground and third platform, when the path on the right of shot was constructed.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the approach footpath. From left to right the three platforms are served by southbound services (1), northbound and eastbound services via Bristol Parkway (2) and services to South Wales (3).
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the northern end of platform 1. From left to right the three platforms are served by southbound services (platform 1), northbound and eastbound services via Bristol Parkway (platform 2) and services to South Wales (platform 3).
Photo by Chris McKenna19/01/2006. |
|
The northern end of platforms 2 and 3 at Filton Abbey Wood station viewed from the northern end of platform 1.
Photo by Chris McKenna19/01/2006. |
|
A merged view of Filton Abbey Wood station, looking south from the northern end of platfom 1.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station viewed from the southern end of platfom 1. Unlike at most stations, and indeed all the other platform ends at this station, the notice prohibiting passengers from walking beyond the specified point is located at the bottom rather than top of the ramp to track level.
Photo by Chris McKenna19/01/2006. |
|
Platforms 2 and 3 at Filton Abbey Wood station viewed from the southern end of platfom 1.
Photo by Chris McKenna19/01/2006. |
|
A merged view of Filton Abbey Wood station photographed from the southern end of platfom 1. Unlike at most stations, and indeed all the other platform ends at this station, the notice prohibiting passengers from walking beyond the specified point is located at the bottom rather than top of the ramp to track level.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station photographed from the northern end of platfom 2. The station was originally constructed with just two platforms, with the shelters set off the back of the platform. In 2004 a third line and platform 3 were constructed to increase line capacity by splitting services for Bristol Parkway and South Wales south of this station.
Photo by Chris McKenna19/01/2006. |
|
Filton Abbey Wood station photographed from the southern end of platfom 2. The station was originally constructed with just two platforms, with the shelters set off the back of the platform. In 2004 a third line and platform 3 (on the left of this picture) were constructed to increase line capacity by splitting services for Bristol Parkway and South Wales south of this station.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station (the footbridge of which can just be seen), viewed through the fence of the car park.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the path between the car park and the station.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the path between the car park and the station.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from footbridge between platforms 1 and 2/3.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the top of the ramp from platform 1.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the northern end of platform 1. The signal in this photograph is a wrong line signal and as such does not get much use.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the halfway landing on the ramp between the footbrdige and platforms 2 and 3.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the halfway landing on the ramp between the footbrdige and platforms 2 and 3. I'm not sure what the point of this very short siding is, but I presume it was truncated when the original path to the station was constructed (this followed the line of the concrete blocks, and was removed when the line on the left of the picture was constructed in 2004).
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station viewed from the halfway landing on the ramp between the footbrdige and platforms 2 and 3. This shows the speed limit for trains heading towards South Wales from platform 2 (not now a common movement) is 40 mph.
Photo by Chris McKenna19/01/2006. |
|
A merged view of the railway line north of Filton Abbey Wood station, viewed from the half-way landing on the ramp between the footbridge and platforms 2 and 3.
Photo by Chris McKenna19/01/2006. |
|
The railway line north of Filton Abbey Wood station, viewed from the half-way landing on the ramp between the footbridge and platforms 2 and 3. This shows the crossover used by southbound trains from South Wales heading for platform 1 at the station.
Photo by Chris McKenna19/01/2006. |
|
The railway line south of Filton Abbey Wood station, viewed from the southern end of platform 1.
Photo by Chris McKenna19/01/2006. |
|
The railway line south of Filton Abbey Wood station, viewed from the southern end of platform 3.
Photo by Chris McKenna19/01/2006. |
|
The railway line south of Filton Abbey Wood station, viewed from the southern end of platform 3.
Photo by Chris McKenna19/01/2006. |
