| The "silkworm" is a new low-floor tram developed by Durmazlar's subsidiary Durmaray. A 27.8 m long, 2.4 m wide standard gauge unidirectional tram with four 100 kW traction motors, for a minimum curve radius of 18 m. The first prototype was shown at the InnoTrans 2012 in Berlin, the first three trains are operating on a 6.5 km line in Bursa. |
| The "silkworm" for Bursa has an unusually flat rear end, much like a bus. InnoTrans 2012, Berlin. |
| The "silkworm" for Bursa, interior looking through one of the articulation joints. InnoTrans 2012, Berlin. |
| The "silkworm" for Bursa, interior. You can see that the wheeled sections have rather big wheel boxes, with sideways oriented seats. InnoTrans 2012, Berlin. |
| The "silkworm" tram for Bursa, interior. Funny signs above the windows, all in english - I guess the turkish language was added for the series production. InnoTrans 2012, Berlin. |
| The "silkworm" tram for Bursa, technical specifications on a sign stuck on a window. InnoTrans 2012, Berlin. |
|
Durmaray Silkworm for Bursa, bidirectional version.
InnoTrans, Berlin, 2014-09-23 to 26 |
|
Durmaray Silkworm for Bursa, bidirectional version.
InnoTrans, Berlin, 2014-09-23 to 26 |
|
Durmaray Silkworm for Bursa, bidirectional version.
InnoTrans, Berlin, 2014-09-23 to 26 |
|
Durmaray Silkworm for Bursa, bidirectional version. Interior.
InnoTrans, Berlin, 2014-09-23 to 26 |
|
Durmaray Silkworm for Bursa, bidirectional version. Interior.
InnoTrans, Berlin, 2014-09-23 to 26 |
|
Durmazlar silkworm tram for Bursa.
InnoTrans, Berlin, 2018-09-21 |
|
Durmazlar silkworm tram for Bursa.
InnoTrans, Berlin, 2018-09-21 |
|
Durmazlar silkworm tram for Bursa.
InnoTrans, Berlin, 2018-09-21 |
|
Durmazlar silkworm tram for Bursa.
InnoTrans, Berlin, 2018-09-21 |
|
Durmazlar silkworm tram for Bursa.
InnoTrans, Berlin, 2018-09-21 |
